Devices deprecated and unsupported in ESXi 7.0 (77304)

Before upgrade to ESXi 7.0 is great to check KB 77304

Deprecated devices in ESXi 7.0 fall into three categories:

If you proceed with the upgrade on a host with any device described in first two categories, the following non-recoverable consequences can occur:

  • You may lose access to storage / data-stores
  • You may lose network access
  • You may lose previous configuration on the host

Deprecated devices supported by VMKlinux drivers

Devices that were only supported in 6.7 or earlier by a VMKlinux inbox driver. These devices are no longer supported because all support for VMKlinux drivers and their devices have been completely removed in 7.0.
PartnerProductDriver
AdaptecAdaptec Rocketaacraid
AdaptecServeRAID 8k/8k-l4aacraid
AdaptecServeRAID 8k/8k-l8aacraid
AdaptecASR-2230S + ASR-2230SLP PCI-Xaacraid
AdaptecASR-2130Saacraid
AdaptecAAR-2820SAaacraid
AdaptecAAR-2620SAaacraid
AdaptecAAR-2420SAaacraid
AdaptecICP9024R0aacraid
AdaptecICP9014R0aacraid
AdaptecICP9047MAaacraid
AdaptecICP9087MAaacraid
AdaptecASR-4810SASaacraid
AdaptecICP5085AUaacraid
AdaptecICP9067MAaacraid
AdaptecCallisto Jupiter Platformaacraid
AdaptecThemisto Jupiter Platformaacraid
AdaptecTomcataacraid
AdaptecAdaptec SCSIaacraid
AdaptecServeRAID 8iaacraid
AdaptecPerc 320/DCaacraid
AdaptecCERC SATA RAID 2 PCI SATA 6ch (DellCosair)aacraid
AdaptecAAR-2610SA PCI SATA 6chaacraid
AdaptecLegend S220aacraid
AdaptecLegend S230aacraid
Adaptec2200S Vulcanaacraid
Adaptec2120S Crusaderaacraid
Adaptec2200S Vulcan-2maacraid
AdaptecAdaptec 3230Saacraid
AdaptecAdaptec 3240Saacraid
AdaptecASR-2020ZCR SCSI PCI-X ZCRaacraid
AdaptecASR-2025ZCR SCSI SO-DIMM PCI-X ZCRaacraid
AdaptecASR-2020SA SATA PCI-X ZCRaacraid
AdaptecASR-2025SA SATA SO-DIMM PCI-X ZCRaacraid
AdaptecAAR-2410SA PCI SATA 4chaacraid
AdaptecAAR-2810SA PCI SATA 8chaacraid
AdaptecAAR-21610SA PCI SATA 16chaacraid
AdaptecESD SO-DIMM PCI-X SATA ZCRaacraid
AdaptecASR-2240Saacraid
AdaptecASR-4005SASaacraid
AdaptecASR-4000SASaacraid
AdaptecASR-4800SASaacraid
AdaptecASR-4800SASaacraid
AdaptecICP9085LI)aacraid
AdaptecICP5085BRaacraid
AdaptecCatapultaacraid
AdaptecThemisto Jupiter Platformaacraid
AdaptecAIC-9410adp94xx
AdaptecAIC-9410adp94xx
AdaptecAIC-9410adp94xx
AdaptecAIC-9410adp94xx
AdaptecAIC-9410adp94xx
AdaptecAIC-7901 U320aic79xx
AdaptecAHA-29320ALPaic79xx
AdaptecAHA-39320Aaic79xx
AdaptecAHA-39320Baic79xx
AdaptecASC-29320LP U320aic79xx
AdaptecASC-29320B U320aic79xx
AdaptecASC-29320 U320aic79xx
AdaptecASC-32320D U320aic79xx
AdaptecASC-32320D U320aic79xx
AdaptecASC-39320D U320aic79xx
AdaptecASC-39320 U320aic79xx
AdaptecASC-29320LP U320 w/HostRAIDaic79xx
AdaptecAIC-7902 U320aic79xx
AdaptecAIC-7901A U320aic79xx
AdaptecAIC-8902 U320 OEMaic79xx
AdaptecAHA-39320DB / AHA-39320DB-HPaic79xx
AdaptecASC-29320A U320aic79xx
AdaptecAIC-7902 U320 w/HostRAIDaic79xx
AdaptecAIC-7901A U320 w/HostRAIDaic79xx
AdaptecServeRAID Controlleripx
AMDAMD 7441 OPUS IDE/PATA Controllerpata_amd
AMDAMD CS5536 IDE/PATA Controllerpata_amd
AMDAMD 8111 IDE/PATA Controllerpata_amd
AMDAMD Viper 7411 IDE/PATA Controllerpata_amd
AMDAMD Viper 7409 IDE/PATA Controllerpata_amd
AMDAMD Cobra 7401 IDE/PATA Controllerpata_amd
AMDAMD Hudson IDE Controllerpata_amd
American MegatrendsMegaRAID 428 Ultra RAID Controllermegaraid2
American MegatrendsMegaRAIDmegaraid2
American MegatrendsMegaRAID 434 Ultra GT RAID Controllermegaraid2
ATI TechnologiesSB700/SB800 IDE Controllerpata_atiixp
BroadcomNetLink BCM5781 Gigabit Ethernettg3
BroadcomNetXtreme BCM5704S Gigabit Ethernettg3
BroadcomNetXtreme BCM5751F Fast Ethernettg3
BroadcomNetXtreme BCM5703 Gigabit Ethernettg3
BroadcomNetXtreme BCM5753M Gigabit Ethernettg3
BroadcomNetXtreme BCM57765 Gigabit Ethernettg3
BroadcomNetXtreme BCM5753 Gigabit Ethernettg3
BroadcomNetXtreme BCM5754 Gigabit Ethernettg3
BroadcomNetXtreme BCM5755 Gigabit Ethernettg3
BroadcomNetLink BCM5786 Gigabit Ethernettg3
BroadcomNetXtreme BCM57766 Gigabit Ethernettg3
BroadcomNetXtreme BCM5702 Gigabit Ethernettg3
BroadcomNetXtreme BCM5703 Gigabit Ethernettg3
BroadcomNetLink BCM5785 Fast Ethernettg3
BroadcomNetLink BCM5906M Fast Ethernettg3
BroadcomNetLink BCM5906 Fast Ethernettg3
BroadcomNetXtreme BCM5761e Gigabit Ethernettg3
BroadcomNetXtreme BCM5705F Fast Ethernettg3
BroadcomNetLink BCM57780 Gigabit Ethernettg3
BroadcomNetXtreme BCM5780S Gigabit Ethernettg3
BroadcomNetXtreme BCM5780 Gigabit Ethernettg3
BroadcomNetXtreme BCM5782 Gigabit Ethernettg3
BroadcomNetXtreme BCM5702FE Gigabit Ethernettg3
BroadcomNetLink BCM57790 Fast Ethernettg3
BroadcomNetXtreme BCM5721 Gigabit Ethernettg3
BroadcomNetXtreme BCM5715 Gigabit Ethernettg3
BroadcomNC326i PCIe Dual Port Gigabit Server Adaptertg3
BroadcomNetXtreme BCM5715S Gigabit Ethernettg3
BroadcomNetXtreme BCM57760 Gigabit Ethernettg3
BroadcomNetLink BCM57788 Gigabit Ethernettg3
BroadcomNetXtreme BCM5756ME Gigabit Ethernettg3
BroadcomNetXtreme BCM5705 Gigabit Ethernettg3
BroadcomNetXtreme BCM5753F Fast Ethernettg3
BroadcomNetXtreme BCM5751 Gigabit Ethernettg3
BroadcomNetXtreme BCM5705 Gigabit Ethernettg3
BroadcomNetXtreme BCM5755M Gigabit Ethernettg3
BroadcomNetXtreme BCM5762 Gigabit Ethernettg3
BroadcomNetLink BCM5787M Gigabit Ethernettg3
BroadcomNetXtreme BCM5714 Gigabit Ethernettg3
BroadcomNetLink BCM5789 Gigabit Ethernettg3
BroadcomNetXtreme BCM57791 Gigabit Ethernettg3
BroadcomNetXtreme BCM57781 Gigabit Ethernettg3
BroadcomNetXtreme BCM57761 Gigabit Ethernettg3
BroadcomNetXtreme BCM5901 100Base-TXtg3
BroadcomNetXtreme BCM57795 Gigabit Ethernettg3
BroadcomNetXtreme BCM57785 Gigabit Ethernettg3
BroadcomNetLink BCM5784M Gigabit Ethernettg3
BroadcomNetLink BCM5787 Gigabit Ethernettg3
BroadcomNetXtreme BCM5764M Gigabit Ethernettg3
BroadcomNetXtreme BCM5702A3 Gigabit Ethernettg3
BroadcomNetXtreme BCM5901 100Base-TXtg3
BroadcomNetXtreme BCM5701 Gigabit Ethernettg3
BroadcomNetXtreme BCM5700 Gigabit Ethernettg3
BroadcomNetXtreme BCM5703 Gigabit Ethernettg3
BroadcomNetXtreme BCM5702 Gigabit Ethernettg3
BroadcomNetXtreme BCM57787 Gigabit Ethernettg3
BroadcomNetXtreme BCM5788 Gigabit Ethernettg3
BroadcomNetXtreme BCM57764 Gigabit Ethernettg3
BroadcomNetXtreme BCM5752M Gigabit Ethernettg3
BroadcomNetXtreme BCM5752 Gigabit Ethernettg3
BroadcomNetXtreme BCM5751M Gigabit Ethernettg3
BroadcomNetXtreme BCM5722 Gigabit Ethernettg3
BroadcomNetXtreme BCM5704S Gigabit Ethernettg3
BroadcomNetXtreme BCM5704 Gigabit Ethernettg3
BroadcomNetXtreme BCM5705M Gigabit Ethernettg3
BroadcomNetXtreme BCM5705M Gigabit Ethernettg3
BroadcomNetXtreme BCM5761 Gigabit Ethernettg3
BroadcomNetXtreme BCM5723 Gigabit Ethernettg3
BroadcomNetXtreme BCM57767 Gigabit Ethernettg3
BroadcomNetXtreme BCM57762 Gigabit Ethernettg3
BroadcomNetXtreme BCM5754M Gigabit Ethernettg3
BroadcomNetXtreme BCM5714S Gigabit Ethernettg3
BroadcomNetXtreme BCM5724 Gigabit Ethernettg3
BroadcomNetXtreme BCM5761SE Gigabit Ethernettg3
BroadcomNetXtreme BCM5761S Gigabit Ethernettg3
BroadcomNetLink BCM5785 Gigabit Ethernettg3
BroadcomNetLink BCM5787F Fast Ethernettg3
CompaqSmart Array 5300cciss
CompaqSmart Array 5icciss
CompaqSmart Array 532cciss
CompaqSmart Array 5312cciss
CompaqSmart Array 6icciss
CompaqSmart Array 641cciss
CompaqSmart Array 642cciss
CompaqSmart Array 6400cciss
CompaqSmart Array 6400 EMcciss
DellPowerEdge Expandable RAID Controller 3/Siaacraid
DellPowerEdge Expandable RAID Controller 2/Siaacraid
Hewlett-Packard PowerEdge Expandable RAID Controller 3/Diaacraid
DellPowerEdge Expandable RAID Controller 3/Diaacraid
DellPowerEdge Expandable RAID Controller 3/Diaacraid
DellPowerEdge Expandable RAID Controller 3/Siaacraid
DellPowerEdge Expandable RAID Controller 3/Diaacraid
DellPowerEdge Expandable RAID Controller 3/Di 1650aacraid
DellPowerEdge Expandable RAID Controller 3/Di 2650aacraid
DellPowerEdge Expandable RAID Controller 5aacraid
DellPowerEdge Expandable RAID Controller 4E/SI/DIaacraid
DellPowerEdge Expandable RAID Controlleraacraid
DellPowerEdge Expandable RAID Controller 4aacraid
Digital Equipment Hewlett-Packard NetRAID-4Maacraid
Digital Equipment AAC-364 (Adaptec 5400S)aacraid
Digital Equipment Adaptec 5400Saacraid
Digital Equipment Dell PowerEdge RAID Controller 2aacraid
Digital Equipment Dell PowerEdge RAID Controller 2aacraid
Hewlett-Packard Smart Array P800cciss
Hewlett-Packard Smart Array P600cciss
Hewlett-Packard Smart Array P400cciss
Hewlett-Packard Smart Array P400icciss
Hewlett-Packard Smart Array E500cciss
Hewlett-Packard Smart Array P600cciss
Hewlett-Packard Smart Array E200icciss
Hewlett-Packard Smart Array E200cciss
Hewlett-Packard Smart Array E200icciss
Hewlett-Packard Smart Array E200icciss
Hewlett-Packard Smart Array E200icciss
Intel Lewisburg SATA AHCI Controllerahci
Intel Lewisburg SATA AHCI Controllerahci
Intel 82547GI Gigabit Ethernet Controllere1000
Intel 82541GI Gigabit Ethernet Controllere1000
Intel 82545GM Gigabit Ethernet Controllere1000
Intel 82546GB Gigabit Ethernet Controllere1000
Intel 82541ER Gigabit Ethernet Controllere1000
Intel 82546GB Gigabit Ethernet Controllere1000
Intel 82541GI Gigabit Ethernet Controllere1000
Intel 82545EM Gigabit Ethernet Controller (Copper)e1000
Intel 82540EM Gigabit Ethernet Controllere1000
Intel 82544GC Gigabit Ethernet Controller (LOM)e1000
Intel 82544GC Gigabit Ethernet Controller (Copper)e1000
Intel 82541EI Gigabit Ethernet Controllere1000
Intel 82547EI Gigabit Ethernet Controllere1000
Intel 82541ER Gigabit Ethernet Controllere1000
Intel 82540EM Gigabit Ethernet Controller (LOM)e1000
Intel 82540EP Gigabit Ethernet Controllere1000
Intel 82540EP Gigabit Ethernet Controllere1000
Intel 82546EB Gigabit Ethernet Controller (Copper)e1000
Intel 82545EM Gigabit Ethernet Controller (Fiber)e1000
Intel 82546EB Gigabit Ethernet Controller (Fiber)e1000
Intel 82541EI Gigabit Ethernet Controllere1000
Intel 82546GB Gigabit Ethernet Controller (Copper)e1000
Intel 82546GB Gigabit Ethernet Controller (Copper)e1000
Intel 82546GB Gigabit Ethernet Controllere1000
Intel 82545GM Gigabit Ethernet Controllere1000
Intel 82545GM Gigabit Ethernet Controllere1000
Intel 82546EB Gigabit Ethernet Controllere1000
Intel 82540EP Gigabit Ethernet Controllere1000
Intel 82547EI Gigabit Ethernet Controllere1000
Intel 82544EI Gigabit Ethernet Controller (Fiber)e1000
Intel 82544EI Gigabit Ethernet Controller (Copper)e1000
Intel 82543GC Gigabit Ethernet Controller (Copper)e1000
Intel 82546GB Gigabit Ethernet Controllere1000
Intel 82541PI Gigabit Ethernet Controllere1000
Intel 82543GC Gigabit Ethernet Controller (Fiber)e1000
Intel 82542 Gigabit Ethernet Controllere1000
Intel 82576NS Gigabit Network Connectionigb
Intel 82576 Gigabit Network Connectionigb
Intel 82576 Gigabit Network Connectionigb
Intel 82576 Gigabit Network Connectionigb
Intel DH8900CC Series Gigabit SFP Network Connectionigb
Intel 82575EB Gigabit Backplane Connectionigb
Intel 82575EB Gigabit Network Connectionigb
Intel 82576 Gigabit Network Connectionigb
Intel DH8900CC Series Gigabit Fiber Network Connectionigb
Intel 82576 Gigabit Network Connectionigb
Intel 82575GB Gigabit Network Connectionigb
Intel DH8900CC Series Gigabit Backplane Network Connectionigb
Intel DH8900CC Series Gigabit Network Connectionigb
Intel 82576 Gigabit Backplane Connectionigb
Intel I210 Gigabit Backplane Network Connectionigb
Intel I210 Gigabit Network Connectionigb
Intel I210 Gigabit Network Connectionigb
Intel 82576NS SerDes Gigabit Network Connectionigb
Intel 82598EB 10-Gigabit Dual Port Network Connectionixgbe
Intel 82598EB 10-Gigabit AT CX4 Network Connectionixgbe
Intel 82598EB 10-Gigabit AF Network Connectionixgbe
Intel 82598EB 10-Gigabit AF Dual Port Network Connectionixgbe
Intel 82598 10GbE PCI-Express Ethernet Controllerixgbe
Intel 82599EB 10Gigabit Dual Port Network Connectionixgbe
Intel 82598EB 10-Gigabit AT Network Connectionixgbe
Intel 82598EB 10-Gigabit AF Network Connectionixgbe
Intel 82599 10 Gigabit Dual Port Backplane Connection with FCoEixgbe
Intel 82598EB 10-Gigabit AT CX4 Network Connectionixgbe
Intel 82598EB Gigabit BX Network Connectionixgbe
Intel 82598EB 10-Gigabit AF Dual Port Network Connectionixgbe
Intel 82598EB 10-Gigabit AT2 Server Adapterixgbe
Intel 82599 10 Gigabit Dual port Network Connection with FCoEixgbe
Intel 82598EB 10-Gigabit AF Dual Port Network Connectionixgbe
Intel MegaRAID 438 Ultra2 LVD RAID Controllermegaraid2
Intel MegaRAID 466 Express Plus RAID Controllermegaraid2
Intel MegaRAID 467 Enterprise 1500 RAID Controllermegaraid2
Intel PowerEdge Expandable RAID Controller 2/SCmegaraid2
Intel PowerEdge Expandable RAID Controller 2/DCmegaraid2
Intel PowerEdge Expandable RAID Controller 2/SCmegaraid2
Intel MegaRAIDmegaraid2
Intel MegaRAID 438, HP NetRAID-3Simegaraid2
Intel MegaRAID T5, Integrated HP NetRAIDmegaraid2
Intel MegaRAID, Integrated HP NetRAIDmegaraid2
IBMServeRAID Controllerips
IBMSCSI RAID Adapter [ServeRAID]ips
LSI/Symbios LogicLSI Logic MegaRAID SATA 300-4XLP SATA II RAID Adaptermegaraid_mbox
LSI/Symbios LogicLSI Logic MegaRAID SATA 300-8XLP SATA II RAID Adaptermegaraid_mbox
LSI/Symbios LogicMegaRAID SAS 1078 Controllermegaraid_sas
LSI/Symbios LogicLSI MegaRAID SAS 1078 Controllermegaraid_sas
LSI/Symbios LogicDell PERC 6/E Adaptermegaraid_sas
LSI/Symbios LogicDell PERC 6/i Adaptermegaraid_sas
LSI/Symbios LogicDell PERC 6/i Integratedmegaraid_sas
LSI/Symbios LogicDell PERC 6/i Integrated Blademegaraid_sas
LSI/Symbios LogicDell CERC 6/i Integratedmegaraid_sas
LSI/Symbios LogicLSI MegaRAID SAS1064megaraid_sas
LSI/Symbios LogicLSI MegaRAID SAS1064Rmegaraid_sas
LSI/Symbios LogicMegaRAID SAS GEN2 SKINNY Controllermegaraid_sas
LSI/Symbios LogicMegaRAID SAS SKINNY Controllermegaraid_sas
LSI/Symbios LogicPERC H310 Integratedmegaraid_sas
LSI/Symbios LogicPERC H310 Reservedmegaraid_sas
LSI/Symbios LogicMegaRAID SAS GEN2 Controllermegaraid_sas
LSI/Symbios LogicDell PERC H800 Adaptermegaraid_sas
LSI/Symbios LogicDell PERC H700 Adaptermegaraid_sas
LSI/Symbios LogicDell PERC H700 Integratedmegaraid_sas
LSI/Symbios LogicDell PERC H700 Modularmegaraid_sas
LSI/Symbios LogicDell PERC H700 / PERC 800megaraid_sas
LSI/Symbios LogicDell PERC H700 / PERC 800megaraid_sas
LSI/Symbios LogicDell PERC H700 / PERC 800megaraid_sas
LSI/Symbios LogicMegaRAID SAS GEN2 Controllermegaraid_sas
LSI/Symbios LogicLSI Logic MegaRAID megaraid2
LSI/Symbios LogicLSI Logic MegaRAIDmegaraid2
LSI/Symbios LogicLSI Logic MegaRAIDmegaraid2
LSI/Symbios LogicDell PERC 4e/DC Adaptermegaraid2
LSI/Symbios LogicLSI Logic MegaRAIDmegaraid2
LSI/Symbios LogicDell PERC 4/DCmegaraid2
LSI/Symbios LogicLSI Logic MegaRAID megaraid2
LSI/Symbios LogicLSI WarpDrive SSDmpt2sas
LSI/Symbios LogicLSI2116_1mpt2sas
LSI/Symbios LogicLSI2116_2mpt2sas
LSI/Symbios LogicLSI2004mpt2sas
LSI/Symbios LogicHP H210i Host Bus Adaptermpt2sas
LSI/Symbios LogicLSI2008mpt2sas
LSI/Symbios LogicDell 6Gbps SAS HBA Adaptermpt2sas
LSI/Symbios LogicDell PERC H200 Adaptermpt2sas
LSI/Symbios LogicDell PERC H200 Integratedmpt2sas
LSI/Symbios LogicDell PERC H200 Modularmpt2sas
LSI/Symbios LogicDell PERC H200 Embeddedmpt2sas
LSI/Symbios LogicDell PERC H200mpt2sas
LSI/Symbios LogicDell 6Gbps SAS HBAmpt2sas
LSI/Symbios LogicIntel(R) SSD 910 Seriesmpt2sas
LSI/Symbios LogicLSI2108_1mpt2sas
LSI/Symbios LogicLSI2108_3mpt2sas
LSI/Symbios LogicLSI2108_2mpt2sas
LSI/Symbios LogicLSI1068Emptsas
LSI/Symbios LogicDell SAS 6/iR Integratedmptsas
LSI/Symbios LogicDell SAS 6/iR Adaptermptsas
LSI/Symbios LogicDell SAS 6/iR Integratedmptsas
LSI/Symbios LogicDell SAS 6/iR Integratedmptsas
LSI/Symbios LogicLSI1064mptsas
LSI/Symbios LogicLSI1078mptsas
LSI/Symbios LogicLSI1064Emptsas
LSI/Symbios LogicLSI1064Amptsas
LSI/Symbios LogicLSI1066Emptsas
LSI/Symbios LogicLSI1068mptsas
LSI/Symbios LogicDell SAS 5/E Adaptermptsas
LSI/Symbios LogicDell SAS 5/i Integratedmptsas
LSI/Symbios LogicDell SAS 5/iR Integratedmptsas
LSI/Symbios LogicDell SAS 5/iR Adaptermptsas
LSI/Symbios LogicLSI1066mptsas
LSI/Symbios Logic53c1030 PCI-X Fusion-MPT Dual Ultra320 SCSImptspi
LSI/Symbios Logic53c1035 PCI-X Fusion-MPT Dual Ultra320 SCSImptspi
LSI/Symbios LogicFC919mptspi
LSI/Symbios LogicFC929Xmptspi
LSI/Symbios LogicFC909mptspi
LSI/Symbios LogicFC929mptspi
LSI/Symbios LogicFC919Xmptspi
Marvell88SE9230 PCIe SATA 6Gb/s Controllerahci
MellanoxMT26428 [ConnectX VPI - 10GigE / IB QDR, PCIe 2.0 5GT/s]mlx4_core
MellanoxMT26488 [ConnectX VPI PCIe 2.0 5GT/s - IB DDR / 10GigE Virtualization+]mlx4_core
MellanoxMT26438 [ConnectX VPI PCIe 2.0 5GT/s - IB QDR / 10GigE Virtualization+]mlx4_core
MellanoxMT25408 [ConnectX VPI - 10GigE / IB SDR]mlx4_core
MellanoxMT27560 Familymlx4_core
MellanoxMT27551 Familymlx4_core
MellanoxMT27550 Familymlx4_core
MellanoxMT27541 Familymlx4_core
MellanoxMT27540 Familymlx4_core
MellanoxMT27531 Familymlx4_core
MellanoxMT25448 [ConnectX EN 10GigE, PCIe 2.0 2.5GT/s]mlx4_core
MellanoxMT25408 [ConnectX EN 10GigE 10GBaseT, PCIe Gen2 5GT/s]mlx4_core
MellanoxMT27561 Familymlx4_core
MellanoxMT26468 [ConnectX EN 10GigE, PCIe 2.0 5GT/s Virtualization+]mlx4_core
MellanoxMT26418 [ConnectX VPI - 10GigE / IB DDR, PCIe 2.0 5GT/s]mlx4_core
MellanoxMT27510 Familymlx4_core
MellanoxMT26488 [ConnectX VPI PCIe 2.0 5GT/s - IB DDR / 10GigE Virtualization+]mlx4_core
MellanoxMT26448 [ConnectX EN 10GigE , PCIe 2.0 5GT/s]mlx4_core
MellanoxMT25418 [ConnectX VPI - 10GigE / IB DDR, PCIe 2.0 2.5GT/s]mlx4_core
MellanoxMT27530 Familymlx4_core
MellanoxMT27521 Familymlx4_core
MellanoxMT27511 Familymlx4_core
MellanoxMT25408 [ConnectX EN 10GigE 10BASE-T, PCIe 2.0 2.5GT/s]mlx4_core
MellanoxMT25408 [ConnectX IB SDR Flash Recovery]mlx4_core
MellanoxMT25400 Family [ConnectX-2 Virtual Function]mlx4_core
NetXenIMEZ 10 Gigabit Ethernetnx_nic
NetXenHMEZ 10 Gigabit Ethernetnx_nic
NetXen10G Ethernet PCI Expressnx_nic
NetXenHP NC510F PCIe 10 Gigabit Server Adapternx_nic
NetXen10G Ethernet PCI Express CXnx_nic
NetXenHP NC510C PCIe 10 Gigabit Server Adapternx_nic
NetXen1G/10G Ethernet PCI Expressnx_nic
NetXenHP NC522m Dual Port 10GbE Multifunction BL-c Adapternx_nic
NetXenHP NC375T PCI Express Quad Port Gigabit Server Adapternx_nic
NetXenHP NC375i 1G w/NC524SFP 10G Modulenx_nic
NetXenHP NC375i Integrated Quad Port Multifunction Gigabit Server Adapternx_nic
NetXenHP NC522SFP Dual Port 10GbE Server Adapternx_nic
NetXenQuanta SFP+ Dual Port 10GbE Adapternx_nic
NetXenDual Port 10GbE CX4 Adapternx_nic
NetXenQLE3044 (NX3-4GBT) Quad Port PCIe 2.0 Gigabit Ethernet Adapternx_nic
NetXenNX3-IMEZ 10 Gigabit Ethernetnx_nic
NetXenQLE3142 (NX3-20GxX) Dual Port PCIe 2.0 10GbE SFP+ Adapternx_nic
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidianVidia NForce Network Controllerforcedeth
nVidiaNVidia NForce MCP61 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP04 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce CK804 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce2 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP65 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce2S IDE/PATA Controllerpata_amd
nVidiaNVidia NForce3 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP67 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP51 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP73 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP77 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce MCP55 IDE/PATA Controllerpata_amd
nVidiaNVidia NForce3S IDE/PATA Controllerpata_amd
nVidiaMCP04 Serial ATA Controllersata_nv
nVidiaCK804 Serial ATA Controllersata_nv
nVidiaCK804 Serial ATA Controllersata_nv
nVidiaMCP61 SATA Controllersata_nv
nVidiaMCP61 SATA Controllersata_nv
nVidiaMCP65 SATA Controllersata_nv
nVidiaMCP65 SATA Controllersata_nv
nVidiaMCP65 SATA Controllersata_nv
nVidiaMCP65 SATA Controllersata_nv
nVidiaCK8S Serial ATA Controller (v2.5)sata_nv
nVidiaMCP55 SATA Controllersata_nv
nVidiaMCP55 SATA Controllersata_nv
nVidiaMCP51 Serial ATA Controllersata_nv
nVidiaMCP51 Serial ATA Controllersata_nv
nVidiaCK8S Serial ATA Controller (v2.5)sata_nv
nVidiaMCP61 SATA Controllersata_nv
nVidiaMCP04 Serial ATA Controllersata_nv
nVidianForce2 Serial ATA Controllersata_nv
nVidiaMCP67 SATA Controllersata_nv
nVidiaMCP67 SATA Controllersata_nv
nVidiaMCP67 AHCI Controllersata_nv
nVidiaMCP67 SATA Controllersata_nv
Promise PDC20276 Ultra ATA/133 IDE/PATA Controllerpata_pdc2027x
Promise PDC20268 Ultra ATA/100 IDE/PATA Controllerpata_pdc2027x
Promise PDC20269 (Ultra133 TX2) IDE/PATA Controllerpata_pdc2027x
Promise PDC20270 Ultra ATA/100 IDE/PATA Controllerpata_pdc2027x
Promise PDC20271 Ultra ATA/133 IDE/PATA Controllerpata_pdc2027x
Promise PDC20275 Ultra ATA/133 IDE/PATA Controllerpata_pdc2027x
Promise PDC20277 Ultra ATA/133 IDE/PATA Controllerpata_pdc2027x
Promise PDC40719 [FastTrak TX4300/TX4310]sata_promise
Promise PDC20619 (FastTrak TX4000)sata_promise
Promise PDC40519 (FastTrak TX4200)sata_promise
Promise PDC20579 SATAII 150 IDE Controllersata_promise
Promise PDC40779 (FastTrak TX2300)sata_promise
Promise PDC20571 (FastTrak TX2200)sata_promise
Promise 20771 (FastTrak TX2300)sata_promise
Promise PDC20319 (FastTrak S150 TX4)sata_promise
Promise PDC20318 (SATA150 TX4)sata_promise
Promise PDC40718 (SATA 300 TX4)sata_promise
Promise PDC20371 (FastTrak S150 TX2plus)sata_promise
Promise PDC20376 (FastTrak 376)sata_promise
Promise PDC20375 (SATA150 TX2plus)sata_promise
Promise PDC20378 (FastTrak 378/SATA 378)sata_promise
Promise PDC20518/PDC40518 (SATAII 150 TX4)sata_promise
Promise PDC20575 (SATAII150 TX2plus)sata_promise
Promise PDC40775 (SATA 300 TX2plus)sata_promise
QlogicNetXtreme II BCM57711 10 Gigabit Ethernetbnx2x
QlogicNetXtreme II BCM57711E 10 Gigabit Ethernetbnx2x
QlogicNetXtreme II BCM57711E/NC532m 10 Gigabit Ethernetbnx2x
QlogicNetXtreme II BCM57711E/NC532i 10 Gigabit Ethernetbnx2x
QlogicNetXtreme II BCM57710 10 Gigabit Ethernetbnx2x
QlogicQLE406Xc iSCSI Host Bus Adapterqla4xxx
QlogicQLA405Xc iSCSI Host Bus Adapterqla4xxx
ServerWorksServerworks OSB4 IDE/PATA Controllerpata_serverworks
ServerWorksServerworks CSB6 IDE/PATA Controllerpata_serverworks
ServerWorksServerworks CSB5 IDE/PATA Controllerpata_serverworks
ServerWorksServerworks HT1100 IDE/PATA Controllerpata_serverworks
ServerWorksServerworks HT1000 IDE/PATA Controllerpata_serverworks
ServerWorksServerworks CSB6IDE2 IDE/PATA Controllerpata_serverworks
ServerWorksBroadCom HT1100 SATA Controller (PATA/IDE Mode)sata_svw
ServerWorksBroadCom HT1100 SATA Controller (NATIVE SATA Mode)sata_svw
Silicon ImageCMD646 IDE/PATA Controllerpata_cmd64x
Silicon ImageCMD643 IDE/PATA Controllerpata_cmd64x
Silicon ImageCMD648 IDE/PATA Controllerpata_cmd64x
Silicon ImageCMD649 IDE/PATA Controllerpata_cmd64x
Silicon ImageSil0680A - PCI to 2 Port IDE/PATA Controllerpata_sil680
Silicon ImageAdaptec AAR-1210SA SATA HostRAID Controllersata_sil
Silicon ImageSiI 3512 [SATALink/SATARaid] Serial ATA Controllersata_sil
Silicon ImageSiI 3114 [SATALink/SATARaid] Serial ATA Controllersata_sil
Silicon ImageSiI 3112 [SATALink/SATARaid] Serial ATA Controllersata_sil
Silicon ImageSiI 3531 [SATALink/SATARaid] Serial ATA Controllersata_sil24
Silicon ImageSiI 3124 [SATALink/SATARaid] Serial ATA Controllersata_sil24
Silicon ImageSiI 3132 [SATALink/SATARaid] Serial ATA Controllersata_sil24
TrionesHPT 366 (rev 06) IDE/PATA Controllerpata_hpt3x2n
TrionesHPT 372 (rev 02) IDE/PATA Controllerpata_hpt3x2n
TrionesHPT 302/302N (rev 02) IDE/PATA Controllerpata_hpt3x2n
TrionesHPT 371/371N (rev 02) IDE/PATA Controllerpata_hpt3x2n
TrionesHPT 372N IDE/PATA Controllerpata_hpt3x2n
VIAVX800 SATA/EIDE Controllerpata_via

Deprecated devices supported by VMKlinux drivers – full table list

Deprecated Devices 7.0 native and not removed in driver

Devices that were supported by a Native inbox driver in 6.7 or earlier but that support has been completely removed in the 7.0 inbox driver.
PartnerDeviceDriver
IntelIntel PRO/1000 PF Dual Port Server Adaptere1000e
EmulexOneConnect OCe11102-Ielxiscsi
EmulexEmulex OneConnect OCe11102 10GbE iSCSI CNAelxiscsi
EmulexOneConnect OCe11102-IMelxiscsi
EmulexOneConnect OCe11102-ITelxiscsi
EmulexOneConnect OCe11102-IXelxiscsi
FujitsuPY CNA Mezz Card 10Gb 2 Port iSCSI (MC-CNA112E)elxiscsi
FujitsuEmulex OneConnect OCl11102-LOM 2-port PCIe 10GbE Converged Network Adapterelxiscsi
FujitsuEmulex OneConnect OCl11102-LOM 2-port PCIe 10GbE Converged Network Adapterelxiscsi
FujitsuEmulex OneConnect OCl11102-LOM 2-port PCIe 10GbE Converged Network Adapterelxiscsi
HitachiOCl11102-F-HIelxiscsi
HitachiOCm11104-F2-HIelxiscsi
HP613431-B21 (HP NC553m) Emulex OneConnect OCe11102 10GbE iSCSI CNA FlexFabric Adapter for HP ProLiant Selxiscsi
HP554FLR-SFP+elxiscsi
HPHP 554Melxiscsi
HP613431-B21 (HP NC553m) Emulex OneConnect OCe11102 10GbE NIC CNA FlexFabric Adapter for HP ProLiant Selxiscsi
HPHP CN1100E Converged Network Adapterelxiscsi
Huawei Technologies Co., Ltd.MZ510elxiscsi
Huawei Technologies Co., Ltd.MZ512elxiscsi
IBMEmulex 10GbE Virtual Fabric Adapter II for IBM System x (49Y7950)elxiscsi
IBMEmulex 10GbE Virtual Fabric Adapter Advanced 2 - IBM BladeCenter (90Y3566)elxiscsi
IBMEmulex 10 GbE Virtual Fabric Adapter III for IBM System x (95Y3762)elxiscsi
IBMIBM Flex System CN4054 10Gb VFA Ethernet (90Y3554)elxiscsi
IBMEmulex Virtual Fabric Adapter II for HS23 (81Y3120)elxiscsi
IBMEmulex 10 GbE Virtual Fabric Adapter IIIr for IBM System x (00D8540)elxiscsi
IBM00D8540 Emulex 10 GbE Virtual Fabric Adapter III for IBM System x (OCe11102R-N2-X)elxiscsi
IBM00D8536 (SBB) Emulex 10 GbE Virtual Fabric Adapter IIIr for IBM System x (OCe111D2R-N2-X)elxiscsi
Lenovo00Y3306 Flex System CN4054R 10Gb Virtual Fabric Adapter (OCm11104R-N-X)elxiscsi
LenovoFlex System CN4054 10Gb VFA Ethernet (90Y3554)elxiscsi
LenovoEmulex Dual Port 10 GbE SFP+ Virtual Fabric Adapter IIIr (00D8540)elxiscsi
LenovoEmulex 10GbE Virtual Fabric Adapter II for HS23 (81Y3120)elxiscsi
LenovoEmulex OCl11104-F-X Virtual Fabric Adapter 2-port 10Gb and 2-port 1Gb LOM for HS-23elxiscsi
EmulexOneConnect 10Gb Gen2 PCIe Network Adapterelxnet
EmulexOneConnect OCe11102-Nelxnet
EmulexEmulex OneConnect OCe11102-NX 10GbE NICelxnet
HP(HP NC553i) Emulex OneConnect OCe11102 10GbE NIC CNA for HP ProLiant Intel G7 BladeSystemselxnet
HPHP NC552melxnet
HP613431-B21 (HP NC553m) Emulex OneConnect OCe11102 10GbE NIC CNA FlexFabric Adapter for HP ProLiant Selxnet
IBMEmulex 10GbE Virtual Fabric Adapter II for IBM System x (49Y7950)elxnet
IBMEmulex 10GbE Virtual Fabric Adapter 2 - IBM BladeCenter (90Y3550) (00Y3266)elxnet
IBMEmulex 10GbE Virtual Fabric Adapter Advanced 2 - IBM BladeCenter (90Y3566)elxnet
HPNC552SFPelxnet
EmulexOCe11102-NMelxnet
EmulexOCe11102-NTelxnet
HP554FLR-SFP+elxnet
HPHP 552Melxnet
HPHP 554FLBelxnet
HPHP 554Melxnet
IBMEmulex 10 GbE Virtual Fabric Adapter III for IBM System x (95Y3762)elxnet
EmulexEmulex OCe11101-NM 10Gb 1-port network adapterelxnet
EmulexEmulex OCe11101-NX 10Gb 1-port network adapterelxnet
IBMIBM Flex System CN4054 10Gb VFA Ethernet (90Y3554)elxnet
IBMEmulex 10GbE Custom Adapter for IBM System X (SBB 49Y7940)elxnet
IBMEmulex Virtual Fabric Adapter II for HS23 (81Y3120)elxnet
HPCN1100E (BK835A)elxnet
LenovoEmulex Dual Port 10Gb SFP+ Embedded VFA IIIr (90Y6456) (00Y7730)elxnet
EmulexOneConnect OCe11102-EXelxnet
EmulexOneConnect OCe11102-EMelxnet
EmulexOneConnect OCe11101-EXelxnet
EmulexOneConnect OCe11101-EMelxnet
HitachiOCl11102-F-HIelxnet
HitachiOCm11104-F2-HIelxnet
HitachiOCm11104-N2-HIelxnet
IBMEmulex 10 GbE Virtual Fabric Adapter IIIr for IBM System x (00D8540)elxnet
IBM00Y3306 IBM Flex System CN4054R 10Gb Virtual Fabric Adapter (OCm11104R-N-X)elxnet
IBMIBM Flex System2-port 10Gb LOM Virtual Fabric Adapter (OCI11102R-F-X)elxnet
IBMIBM Flex System 2-port 10Gb LOM Virtual Fabric Adapter (OCl11102F-X)elxnet
IBMx440 (OCI11102-F5-X)elxnet
IBMIBM Flex System 2-port 10Gb LOM Virtual Fabric Adapter (OCI11102-F7-X)elxnet
IBMIBM Flex System 2-port 10Gb LOM Virtual Fabric Adapter (OCI11102-F6-X)elxnet
Huawei Technologies Co., Ltd.MZ510elxnet
Huawei Technologies Co., Ltd.MZ512elxnet
Lenovo00Y3306 Flex System CN4054R 10Gb Virtual Fabric Adapter (OCm11104R-N-X)elxnet
LenovoFlex System CN4054 10Gb VFA Ethernet (90Y3554)elxnet
LenovoEmulex Dual Port 10 GbE SFP+ Virtual Fabric Adapter IIIr (00D8540)elxnet
LenovoEmulex 10GbE Virtual Fabric Adapter II for HS23 (81Y3120)elxnet
LenovoEmulex 10GbE Virtual Fabric Adapter II -for BladeCenter (90Y3550) (00Y3266)elxnet
FujitsuPY CNA Mezz Card 10Gb 2 Port NIC (MC-CNA112E)elxnet
Lenovo90Y9332 Emulex 10GbE Virtual Fabric Adapter Advanced II for HS23elxnet
Lenovo00Y3264 Emulex 10GbE Virtual Fabric Adapter Advanced II for BladeCenterelxnet
FujitsuOneConnect OCl11104-F1-Felxnet
FujitsuOneConnect OCl11104-F2-Felxnet
FujitsuOneConnect OCl11104-F3-Felxnet
LenovoEmulex OCl11104-F-X Virtual Fabric Adapter 2-port 10Gb and 2-port 1Gb LOM for HS-23elxnet
HPHP BL8X0c i3 Dual Port FlexFabric 10Gb Embedded CNICelxnet
HPHP Integrity_CN1100E PCIe 2-port CNAelxnet
HPHP Integrity NC552SFP 2P 10GbE Adapterelxnet
HPHP OCl11102-F5-HP Dual Port FlexFabric 10Gb Embedded CNICelxnet
HPHP AT093A 10GbE-SFP PCIe 1p 8Gb FC and 1p 1/10GbE Adtrelxnet
HPHP AT094A 10GbE-SFP PCIe 2p 8Gb FC and 2p 1/10GbE Adtrelxnet
HPEmulex OneConnect OCe11102-I-HP NICelxnet
HPEmulex OneConnect OCm11102-I-HP NICelxnet
LSIMegaRAID SAS 9265-8ilsi_mr3
IntelIntel RAID Controller RMS25CB040lsi_mr3
IntelIntel RAID Controller RMS25CB080lsi_mr3
IntelIntel RAID Controller RMS25CB080Nlsi_mr3
FujitsuSAS RAID HDD Module w/o Cache (D2837)lsi_mr3
FujitsuSAS RAID HDD Module (D2816C )lsi_mr3
FujitsuSAS RAID HDD Module w/o Cache (D2837C )lsi_mr3
FujitsuRAID Ctrl SAS 6G 1GB (D3116)lsi_mr3
FujitsuSAS RAID HDD Module (D2816)lsi_mr3
FujitsuRAID Ctrl SAS 6G 1GB (D3116C)lsi_mr3
LSIMegaRAID SAS 9286CV-8elsi_mr3
LSIMegaRAID SAS 9271-4ilsi_mr3
LSIMegaRAID SAS 9266-8ilsi_mr3
LSIMegaRAID SAS 9266-4ilsi_mr3
LSIMegaRAID SAS 9286CV-8eCClsi_mr3
LSIMegaRAID SAS 9270-8ilsi_mr3
LSIMegaRAID SAS 9271-8ilsi_mr3
LSIMegaRAID SAS 9271-8iCClsi_mr3
LSIMegaRAID SAS 9286-8elsi_mr3
LSIMegaRAID 9285CV-8elsi_mr3
LSIMegaRAID SAS 9285-8elsi_mr3
Supermicro Computer IncSMC2208lsi_mr3
IntelIntel RAID Controller RMS25PB080Nlsi_mr3
IntelIntel RAID Controller RMS25PB080lsi_mr3
IntelIntel RAID Controller RMS25PB040lsi_mr3
IntelIntel RAID Controller RS25DB080lsi_mr3
LenovoServeRAID M5110 SAS/SATA Controllerlsi_mr3
LenovoServeRAID M5115 SAS/SATA Controller for Flex Systemlsi_mr3
LSINytro MegaRAID NMR 8110-4ilsi_mr3
LSINytro MegaRAID NMR 8120-4ilsi_mr3
LSINytro MegaRAID NMR 8100-4ilsi_mr3
LSINytro MegaRAID NMR 8120-4elsi_mr3
LSINytro MegaRAID NMR 8110-4elsi_mr3
LSINytro MegaRAID NMR 8115-8e8ilsi_mr3
LSINytro MegaRAID NMR 8140-8e8ilsi_mr3
LSIMegaRAID SAS 9265CV-8ilsi_mr3
LSIMegaRAID SAS 9270CV-8ilsi_mr3
LSILSI 2208Rlsi_mr3
LSIMegaRAID SAS 9272-8ilsi_mr3
LSIMegaRAID SAS 9267-8ilsi_mr3
CiscoUCS-RAID9271CV-8Ilsi_mr3
Huawei Technologies Co., Ltd.SR320BClsi_mr3
LenovoServeRAID M5110e SAS/SATA Controllerlsi_mr3
Huawei Technologies Co., Ltd.RU320BClsi_mr3
LenovoFlex System Storage Expansion Node (LSI SAS2208 6 Gbps RAID on Chip (ROC) controller)lsi_mr3
LenovoServeRAID M5120 SAS/SATA Controllerlsi_mr3
Huawei Technologies Co., Ltd.SR420BClsi_mr3
LSIMegaRAID SAS Thunderbolt Controllerlsi_mr3
LenovoServeRAID M5110e SAS/SATA Controllerlsi_mr3
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2308_3 PCI-Expresslsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2208_1 PCI-Expresslsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2208_2 PCI-Expresslsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2208_3 PCI-Expresslsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2208_4 PCI-Expresslsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2208_5 PCI-Expresslsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2208_6 PCI-Expresslsi_msgpt2
Supermicro Computer IncSMC2308lsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2308_1 PCI-Expresslsi_msgpt2
LSISAS9205-8elsi_msgpt2
LSISAS9207-8elsi_msgpt2
LSISAS9215-8ilsi_msgpt2
LSISAS9215-4i4elsi_msgpt2
LSISAS9205-4i4e(H222)lsi_msgpt2
LSISAS9205-8i(H220)lsi_msgpt2
LSISAS9205-8i(H220i)lsi_msgpt2
LSISAS9217-8ilsi_msgpt2
LSISAS9217-4i4elsi_msgpt2
LSISAS9207-8ilsi_msgpt2
LSISAS9206-16elsi_msgpt2
LSISAS9207-4i4elsi_msgpt2
IntelIntel RAID Controller RMS25JB080lsi_msgpt2
IntelIntel RAID Controller RS25FB044lsi_msgpt2
IntelIntel RAID Controller RMS25JB040lsi_msgpt2
IntelIntel® Integrated RAID Module RMS25KB040lsi_msgpt2
IntelIntel® Integrated RAID Module RMS25KB080lsi_msgpt2
LSILSI SAS2308lsi_msgpt2
DELLLSI SAS 9207-8ilsi_msgpt2
Huawei Technologies Co., Ltd.SR120lsi_msgpt2
InspurInspur 2308IRlsi_msgpt2
LenovoN2115 SAS/SATA HBAlsi_msgpt2
LenovoN2125 SAS/SATA HBAlsi_msgpt2
LenovoH701-L (ZAH90)lsi_msgpt2
Huawei Technologies Co., Ltd.RU120lsi_msgpt2
LSIAvago (LSI) Logic Fusion-MPT 6GSAS SAS2308_2 PCI-Expresslsi_msgpt2
LSISAS9207-8e(H221)lsi_msgpt2
Intel82571EB Gigabit Ethernet Controllerne1000
IntelPRO/1000 PB Dual Port Server Connectionne1000
IntelPRO/1000 PB Dual Port Server Connectionne1000
IntelIntel PRO/1000 PB Dual Port Server Connectionne1000
Intel82571EB Gigabit Ethernet Controllerne1000
IntelPRO/1000 PT Dual Port Server Connectionne1000
IntelPRO/1000 PT Dual Port Network Connectionne1000
IntelPRO/1000 PT Dual Port Server Adapterne1000
IntelIntel PRO/1000 PT Dual Port Network Connectionne1000
IntelIntel PRO/1000 PT Dual Port Server Adapterne1000
IntelIntel PRO/1000 PT Dual Port Server Adapterne1000
IntelIntel PRO/1000 PT Dual Port Server Adapterne1000
IntelIntel 82571EB Gigabit Ethernet Controllerne1000
Intel82572EI Gigabit Ethernet Controller (Copper)ne1000
IntelPRO/1000 PT Server Adapterne1000
IntelIntel PRO/1000 PT Network Connectionne1000
IntelIntel PRO/1000 PT Server Adapterne1000
IntelPRO/1000 PF Server Adapterne1000
IntelPRO/1000 PF Server Adapterne1000
Intel82572EI Gigabit Ethernet Controller (Fiber)ne1000
IntelIntel PRO/1000 PF Server Adapterne1000
IntelIntel PRO/1000 PF Network Connectionne1000
Intel82572EI Gigabit Ethernet Controllerne1000
IntelIntel PRO/1000 PB Server Connectionne1000
Intel82573V Gigabit Ethernet Controller (Copper)ne1000
Intel82573E Gigabit Ethernet Controller (Copper)ne1000
IntelPRO/1000 PL Network Connectionne1000
Intel82573L Gigabit Ethernet Controllerne1000
IntelPRO/1000 PT Quad Port Server Adapterne1000
IntelPRO/1000 PT Quad Port Server Adapterne1000
Intel82571EB Gigabit Ethernet Controllerne1000
IntelIntel PRO/1000 PT Quad Port Server Adapterne1000
IntelPRO/1000 PF Quad Port Server Adapterne1000
IntelPRO/1000 PF Quad Port Server Adapterne1000
Intel82571EB Gigabit Ethernet Controller (Fiber)ne1000
IntelIntel PRO/1000 PF Quad Port Server Adapterne1000
IntelPRO/1000 PT Desktop Adapterne1000
IntelPRO/1000 PT Desktop Adapterne1000
Intel82572EI Gigabit Ethernet Controller (Copper)ne1000
IntelPRO/1000 PT Quad Port LP Server Adapterne1000
Intel82571EB Gigabit Ethernet Controller (Copper)ne1000
IntelPRO/1000 PT Quad Port LP Server Adapterne1000
IntelIntel PRO/1000 PT Quad Port LP Server Adapterne1000
Intel82571PT Gigabit PT Quad Port Server ExpressModulene1000
Intel82571EB Dual Port Gigabit Mezzanine Adapterne1000
Intel82571EB Quad Port Gigabit Mezzanine Adapterne1000
Intel82567LM-4 Gigabit Network Connectionne1000
Intel82577LM Gigabit Network Connectionne1000
Intel82577LC Gigabit Network Connectionne1000
Intel82578DM Gigabit Network Connectionne1000
Intel82578DC Gigabit Network Connectionne1000
QLogicISP2432-based 4Gb Fibre Channel to PCI Express HBAqlnativefc
QLogicQME2472qlnativefc
OracleSG-XPCIE1FC-QF4qlnativefc
OracleSG-XPCIE2FC-QF4qlnativefc
EMCQlogic QLE2462-E-SPqlnativefc
DELLQLogic QME2472qlnativefc
DELLQLogic QLE2460qlnativefc
DELLQLogic QLE2462qlnativefc
EMCQlogic QLE2460-E-SPqlnativefc
DELLQME2462qlnativefc
IBMQLE2460 QLogic 4Gb FC Single Port PCIe for IBM System xqlnativefc
IBMQLE2462 QLogic 4GB FC Dual Port PCIe for IBM System xqlnativefc
QLogicQLE2462qlnativefc
QLogicQLE2460qlnativefc
IBMQLogic 4Gb PCIe FC Single-port HBA for IBM System x (39R6525) (QLE2460)qlnativefc
Hitachi VantaraQLE2462-HDS-SPqlnativefc
Hitachi VantaraQLE2460-HDS-SPqlnativefc
IBMQLogic CFFh Ethernet/Fibre Combo Expansion Card for IBM BladeCenter (39Y9306) (QMI3472)qlnativefc
OracleSG-XPCIE2FCGBE-Q-Z (QEM3472)qlnativefc
QLogic2400 Series 4Gb Fibre Channelqlnativefc
IBMQLE2462-IBMqlnativefc
IBMQLE2460-IBMqlnativefc
QLogicISP2432-based 4Gb Fibre Channel to PCI Express HBAqlnativefc
QLogicISP2422-based 4Gb Fibre Channel to PCI Express HBAqlnativefc
EMCQlogic QLA2460-E-SPqlnativefc
EMCQlogic QLA2462-E-SPqlnativefc
Hitachi VantaraQLA2462-HDS-SPqlnativefc
Hitachi VantaraQLA2460-HDS-SPqlnativefc
IBMQLogic 8Gb FC Dual-port HBA for System xqlnativefc
IBMDS4000 FC 4Gbps PCI-X Dual Port HBA (39M5895) (QLA2462)qlnativefc
IBMDS4000 FC 4Gbps PCI-X Single Port HBA (39M5894) (QLA2460)qlnativefc
IBMQLogic 4Gb FC Expansion (CFFv) (41Y8527) (QMI2472)qlnativefc
IBMQLogic 4 Gb Fibre Channel Expansion (26R0884) (QMC2462)qlnativefc
LSILSI MegaRAID SAS 9240-8ilsi_mr3
LSILSI MegaRAID SAS 9241-4ilsi_mr3
LSIServeRAID M1015 SAS/SATA Controllerlsi_mr3
IntelIntel ® Server RAID Controller RS2WC080lsi_mr3
IntelIntel ® Server RAID Controller RS2WC040lsi_mr3
IBMServeRAID M1115 SAS/SATA Controller for System x (81Y4448)lsi_mr3
LSILSI MegaRAID SAS 9240-8ilsi_mr3
LSILSI MegaRAID SAS 9220-4ilsi_mr3
LSILSI MegaRAID SAS 9220-8ilsi_mr3
LSILSI SAS2008lsi_mr3
LSILSI SAS2004lsi_mr3
LSIUCSC-RAID-MZ-220lsi_mr3
LSIUCSC-RAID-11-C220 Cisco UCSC RAID SAS 2008M-8i Mezzanine Cardlsi_mr3
CiscoCisco UCS-E MegaRAID SAS 2004 ROMBlsi_mr3
LSIUCSC-RAID-MZ-240lsi_mr3
LSIUCSC-RAID-11-C240lsi_mr3
Huawei Technologies Co., Ltd.MZ910lpnic
Huawei Technologies Co., Ltd.MZ910lpnic
Huawei Technologies Co., Ltd.MZ910elxnet
Huawei Technologies Co., Ltd.MZ910elxnet
Huawei Technologies Co., Ltd.MZ910lpfc
Huawei Technologies Co., Ltd.MZ220lpnic
Huawei Technologies Co., Ltd.MZ220lpfc
Huawei Technologies Co., Ltd.MZ220elxnet
Huawei Technologies Co., Ltd.MZ912lpnic
Huawei Technologies Co., Ltd.MZ912lpfc
Huawei Technologies Co., Ltd.MZ912elxnet
EMCEMC OCe11102-FX-E 10Gb CNAlpfc
EmulexOneConnect OCe11102-Flpfc
EmulexEmulex OCe11102-FMlpfc
EmulexOCe11102-FXlpfc
FujitsuMC-CNA112E PY CNA Mezz Card 10Gb 2 Portlpfc
FujitsuEmulex OneConnect OCl11102-LOM 2-port PCIe 10GbE Converged Network Adapterlpfc
FujitsuEmulex OneConnect OCl11102-LOM 2-port PCIe 10GbE Converged Network Adapterlpfc
FujitsuEmulex OneConnect OCl11102-LOM 2-port PCIe 10GbE Converged Network Adapterlpfc
HitachiOCm11104-F2-HIlpfc
HitachiOCl11102-F-HIlpfc
HP(HP NC553i) Emulex OneConnect OCe11102 10GbE FcoE CNA for HP ProLiant Intel G7 BladeSystemselxnet
HP613431-B21 (HP NC553m) Emulex OneConnect OCe11102 10GbE FCoE CNA FlexFabricelxnet
HPCN1100E (BK835A)lpfc
HP554FLR-SFP+lpfc
HPHP 554FLBlpfc
HPHP 554Mlpfc
Huawei Technologies Co., Ltd.MZ510lpfc
Huawei Technologies Co., Ltd.MZ512lpfc
IBMEmulex 10 GbE Virtual Fabric Adapter III for IBM System x (95Y3762)lpfc
IBMIBM OCm11102-F-XL Emulex Virtual Fabric Adapter Advanced (CFFh, 2+2)brcmfcoe
IBMEmulex OCl11104-F-X Virtual Fabric Adapter 2-port 10Gb and 2-port 1Gb LOMelxnet
IBMIBM OCm11104-N-X Emulex Virtual Fabric Adapter (Fabric Mezz)elxnet
IBMEmulex OCl11102-F-X Virtual Fabric Adapter 2-port 10Gb LOMelxnet
IBMIBM OCm11102-F-XL Emulex Virtual Fabric Adapter Advanced (CFFh, 2+2)elxnet
LenovoFlex System CN4054 10Gb VFA Ethernet (90Y3554)brcmfcoe
LenovoEmulex 10GbE Virtual Fabric Adapter II for HS23 (81Y3120)brcmfcoe
LenovoEmulex Dual Port 10 GbE SFP+ Virtual Fabric Adapter IIIr (00D8540)brcmfcoe
Lenovo00Y3306 Flex System CN4054R 10Gb Virtual Fabric Adapter (OCm11104R-N-X)elxnet
LenovoEmulex OCl11104-F-X Virtual Fabric Adapter 2-port 10Gb and 2-port 1Gb LOM for HS-23brcmfcoe
SugonSugon 10GEEC02-U10 2-port 10GbE Converged Network Adapter Blade Mezzlpfc

Deprecated Devices native and not removed in drivers – full table list

Deprecated devices supported by Native drivers

Devices that were supported by a Native inbox in 6.7 or earlier and will recognized by 7.0 but are no longer supported in 7.0 and will be completely removed from the driver in a subsequent release.
PartnerProductDriver
Intel82566MM Gigabit Network Connectionne1000
Intel80003ES2LAN Gigabit Ethernet Controller (Copper)ne1000
IntelIntel PRO/1000 EB Network Connection with I/O Accelerationne1000
Intel80003ES2LAN Gigabit Ethernet Controller (Serdes)ne1000
IntelIntel PRO/1000 EB Backplane Connection with I/O Accelerationne1000
Intel82567V-3 Gigabit Network Connectionne1000
Intel82566DM Gigabit Network Connectionne1000
Intel82566DC Gigabit Network Connectionne1000
Intel82562V 10/100 Network Connectionne1000
Intel82566MC Gigabit Network Connectionne1000
Intel80003ES2LAN Gigabit Ethernet Controller (Copper)ne1000
IntelIntel PRO/1000 EB1 Network Connection with I/O Accelerationne1000
Intel80003ES2LAN Gigabit Ethernet Controller (Serdes)ne1000
IntelIntel PRO/1000 EB1 Backplane Connection with I/O Accelerationne1000
Intel82566DM-2 Gigabit Network Connectionne1000
Intel82567LF Gigabit Network Connectionne1000
Intel82562V-2 10/100 Network Connectionne1000
Intel82562G-2 10/100 Network Connectionne1000
Intel82562GT-2 10/100 Network Connectionne1000
Intel82562GT 10/100 Network Connectionne1000
Intel82562G 10/100 Network Connectionne1000
Intel82567V Gigabit Network Connectionne1000
Intel82567LM-2 Gigabit Network Connectionne1000
Intel82567LF-2 Gigabit Network Connectionne1000
Intel82567V-2 Gigabit Network Connectionne1000
Intel82567LM-3 Gigabit Network Connectionne1000
Intel82567LF-3 Gigabit Network Connectionne1000
Intel82567LM Gigabit Network Connectionne1000
Intel82566DC-2 Gigabit Network Connectionne1000

Deprecated devices supported by Native drivers – full table list

Author: Daniel Micanek

Senior Service Architect, SAP Platform Services Team at TietoEVRY | vExpert ⭐⭐ | VCIX-DCV 2021 | VCAP-NV Design 2020 | VCAP-DCV Design 2021 | VCAP-DCV Deploy 6 | VCP-DCV 2020 | VCP-NV 2020 | NCIE-DP | OCP | Azure Solutions Architect
